iglidur® X6, sleeve bearing with flange, mm

  • Good wear resistance at medium high temperatures
  • Very good wear resistance at high temperatures
  • Suitable for extremely high speeds
  • Very low humidity absorption
  • Good wear resistance under water
  • Very high media resistance
  • Resistant to high loads (>60 N/mm²)
  • Electrically conductive
Product description
iglidur® X6 | Runs up to six times longer than iglidur® X
Due to nano-technology, iglidur® X6 shows up to six times better performance than iglidur® X in many oscillating and rotating applications – even at temperatures over +100 °C.

Typical application areas

Fluid technology
Glass industry
Food industry
Machine tools
Textile industry

You can find further applications here:
Industry solutions

When to use it?
  • If temperatures are higher than +150 °C
  • When the wear performance of iglidur® X in oscillation and rotation is not sufficient
  • If the press-fit should be improved over iglidur® X
  • If high media resistance is required
  • If PTFE-free bearing is required
When not to use it?
Use our filter options to find the suitable product

Tolerances and measurement system
The installation dimensions and tolerances of iglidur® plain bearings are a function of the material and wall thicknesses. For each material, the moisture absorption and the thermal expansion are decisive factors. Plain bearings with low moisture absorption can be designed with a minimal bearing clearance. The rule for wall thickness: the thicker the wall of the bearings, the larger the clearances must be.
Testing methods

Assembly
iglidur® plain bearings are press-fit bearings. The inner diameter adjusts only after press-fitting in the correctly toleranced housing. The press-fit excess dimension can be up to 2% of the inner diameter. This ensures the secure press-fitting of the bearing. Axial or radial movement in the housing are prevented this way.
iglidur® - assembling, gluing, machining

Certificate si standarde
RoHS compliant
According to 2011/65/EU (RoHS 2)
